Rare radiograph finding: Kohler disease

A previously healthy 3-year-old male presented to the emergency department with one day of refusal to bear weight secondary to left foot pain. No known trauma. No fever or recent illness. On physical examination, he had point tenderness over the proximal dorsal left foot with minimal swelling. No erythema or warmth. He would only crawl, which was abnormal per his mother. Plain radiographs of the left foot revealed a thin, fragmented and sclerotic navicular bone (Figures 1,2).

Figure 1 Oblique view of left foot. Arrow pointing to flatten and sclerotic navicular bone.

Figure 2 Lateral view of left foot. Arrow pointing to flatten and sclerotic navicular bone.

The patient received a diagnosis of Kohler disease. Kohler disease is a condition impacting the pediatric population that is characterized by idiopathic avascular necrosis of the navicular bone (1,2). Kohler disease was first described by radiologist Alban Kohler in 1908 (2,3). Children with Kohler disease typically present with limping, reluctance to apply pressure to the foot, pain and swelling without a history of injury or infectious signs. Radiographs demonstrate sclerosis, flattening, and fragmentation of the navicular bone. Kohler disease is most commonly seen in males ages 4 to 7 years old (2,3). Our patient was 3 years old, suggesting this pathology is possible in a younger population as well.

It has been hypothesized Kohler disease may be secondary to repetitive trauma inflicted on the navicular bone by the adjacent tarsal bones, compromising the vascular supply (1,2). The navicular is the last tarsal bone to ossify and thus is vulnerable to getting squished between the harder, already ossified talus and cuneiforms (1,3). As a result, the blood vessels supplying the navicular bone are compressed, which interrupts blood supply and leads to ischemia of the central spongy bone. The navicular bone ossifies later in males than females (18 to 24 months old in females, 30 to 36 months old in males), which explains the increased incidence of Kohler disease in males (1). The dual blood supply of the navicular bone likely also contributes to disease development (3). The medial tarsal branch of the dorsalis pedis artery supplies the medial aspect of the navicular. The medial plantar branch of the posterior tibial artery supplies the lateral aspect of the navicular. In the central navicular, there is a region of watershed blood supply. This zone of relative hypovascularity results in an increased risk of ischemia and thus avascular necrosis as seen in Kohler disease and has also been described in prior literature in association with navicular stress fractures and poor healing (3,4).

Kohler disease is managed nonoperatively (1). Once diagnosed, patients should be referred to pediatric orthopedics for further management. Non-steroidal anti-inflammatory drugs (NSAIDs) can be used for pain relief but do not shorten the duration of the disease (3). Literature has demonstrated earlier symptomatic improvement in patients who were treated with immobilization in a short leg walking cast (5). Further investigations are necessary to determine the efficacy of weight-bearing casts compared to non-weight-bearing casts in regards to shortening the duration of Kohler disease. Offloading orthotics, such as soft arch supports, can also be used to provide symptomatic relief as either the sole therapy modality or preceding and/or proceeding treatment with a short leg cast (3).

Kohler disease has a very favorable prognosis. Both symptoms and radiographs should start to show improvement in around six months from onset (3). All patients recover excellent function in the foot and have complete radiographic resolution in an average of two to three years (3). There are no reports to date of chronic symptoms or disability resulting from Kohler disease (1,3,5). Significant pain persisting longer than 6 months despite proper treatment likely suggests a separate or adjacent underlying condition, for example, tarsal coalition, and would necessitate further work up such as computed tomography (CT) or magnetic resonance imaging (MRI).

Pediatric orthopedics placed our patient in a walking boot for six weeks. At follow-up, the patient was pain free and ambulating at baseline. Kohler disease is rare but should be considered in the differential diagnosis for children with refusal to bear weight, especially in cases without preceding injury and without evidence of infection or malignancy. Recognition of this diagnosis may prevent additional unnecessary tests in an emergency department or clinic setting.

Acknowledgments

Funding: None.

Footnote

Provenance and Peer Review: This article was a standard submission to the journal. The article has undergone external peer review.

Peer Review File: Available at https://jeccm.amegroups.com/article/view/10.21037/jeccm-24-34/prf

Conflicts of Interest: Both authors have completed the ICMJE uniform disclosure form (available at https://jeccm.amegroups.com/article/view/10.21037/jeccm-24-34/coif). The authors have no conflicts of interest to declare.

Ethical Statement: The authors are accountable for all aspects of the work in ensuring that questions related to the accuracy or integrity of any part of the work are appropriately investigated and resolved. All procedures performed in this study were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient’s parents for publication of this article and accompanying images. A copy of the written consent is available for review by the editorial office of this journal.

Open Access Statement: This is an Open Access article distributed in accordance with the Creative Commons Attribution-NonCommercial-NoDerivs 4.0 International License (CC BY-NC-ND 4.0), which permits the non-commercial replication and distribution of the article with the strict proviso that no changes or edits are made and the original work is properly cited (including links to both the formal publication through the relevant DOI and the license). See: https://creativecommons.org/licenses/by-nc-nd/4.0/.

References

1. Chan JY, Young JL. Köhler Disease: Avascular Necrosis in the Child. Foot Ankle Clin 2019;24:83-8. [Crossref] [PubMed]
2. Alhamdani M, Kelly C. Kohler's disease presenting as acute foot injury. Am J Emerg Med 2017;35:1787.e5-6. [Crossref] [PubMed]
3. Trammell AP, Davis DD, Scott A. Kohler Disease. Treasure Island (FL): StatPearls Publishing; 2024.
4. Patel KA, Christopher ZK, Drakos MC, et al. Navicular Stress Fractures. J Am Acad Orthop Surg 2021;29:148-57. [Crossref] [PubMed]
5. Williams GA, Cowell HR. Köhler's disease of the tarsal navicular. Clin Orthop Relat Res 1981;53-8. [PubMed]
